Magnuson Heartbeat Supercharger C7 LT1 Corvette

$9,454.00

CHEVROLET Corvette C7
LT1 6.2L V8 Stingray
HEARTBEAT SUPERCHARGER SYSTEM

Features:

  • TVS2300 Heartbeat Hybrid-roots supercharger
  • Clears the factory Corvette hood and requires no body modifications
  • TVS2300 Front-Inlet Front-Drive rotors, utilizes the same Eaton technology as the Corvette ZR1 LS9
  • Provides cooler discharge temperatures than comparable twin-screw systems
  • Advanced high-flow inlet forward design
  • Includes Twin dual-pass charge-air-coolers utilise Formula-1 racing thermal-control technology
  • Acoustically designed to minimize noise, vibration, and harshness (NVH)
  • Better air-handling characteristics than comparable superchargers
  • 100% complete bolt-on system which can be installed in one day
  • More power in a smaller package
  • Internal Bypass Valve virtually eliminates parasitic loss (uses less than 1/3 of a horsepower at 60 mph)
  • Delivers a proven increase in real world “under the curve” power
  • High thermal efficiency
  • 2.4 pressure ratio capability
  • High helix four-lobe rotors with 160 degrees of twist
  • Redesigned inlet and outlet ports
  • Utilizes all factory “push-lock” connectors
  • Displacement on demand hardware retained for improved fuel economy
  • Components have been independently tested to GM’s specification

Out of stock

The most powerful underhood Corvette Supercharger on the market
Magnuson is proud to announce our under the hood Heartbeat supercharger system is now available for the 2014-2017 Chevrolet Corvette C7 Stingray. At just 6 psi, the Heartbeat adds over 120hp to the wheels, to give you over 630 hp at the crank. The new Heartbeat for the C7 Corvette fits completely underhood, requiring no spacers, and allowing you to keep your Stingray hoodliner.

Run cooler with the most advanced intercooler system available
Heat soak can be a problem in underhood supercharger systems, robbing more than half the power gain in the summer heat or after a few dragstrip runs. Heartbeat features integrated intercoolers derived from the same technology used in Formula 1 and NASCAR heat exchangers. Unlike other underhood supercharger systems, customers report low IATs and consistent performance all day long.

Intercooler System


  • Twin dual-pass charge-air-coolers utilise Formula-1 racing thermal-control technology
  • Back-to-back testing verifies the intercooler system is superior
  • Quick-connect fittings for easier installation

Upgrade Options


  • Upgradable throttle body adaptor available for large throttle bodies
  • Drive pulley options available for high-boost applications

Included Components


  • 6th Generation TVS2300 Heartbeat Supercharger with integral bypass valve
  • Patented cast-aluminum high-velocity-port intake manifold
  • Twin dual-pass charge-air-coolers utilise Formula-1 racing thermal-control technology
  • Large front-mounted heat exchanger
  • All necessary fittings, lines, belts, and hardware required

Warranty


  • Standard 3-year/36,000 mile Warranty on the supercharger hardware
  • Standard 1-year Limited Warranty on electronics
  • Standard Power Train – 3 Year / 36,000 Mile Limited Power Train Warranty
  • Optional Power Train – 5 Year / 60,000 Mile Limited Power Train Warranty

Maintenance


  • Sealed supercharger rotor assembly requires no maintenance or oil change

Average Installation Time


  • 10-12 Hours

Additional information

Weight 125 lbs
Dimensions 34 × 34 × 18 in
Model

2010-2010 Camaro, 2013-2015 Camaro
